Data Loggers

Graphtec Data Logging & Instrumentation Equipment

“Test & Measurement instruments can often add heavy loads to R&D cost and engineering labor hours due to their sophisticated software mechanisms and integration.

Graphtec Data Loggers & Data Acquisition Platforms eliminate these problems with a versatile system that launches test applications quickly and cost effectively.”

What Data Loggers Offer:
• Portability & Versatility For Onsite-Testing Needs
• Multi-Function Inputs For Multiple Signal Recordings
• Channel To Channel Isolation For Enhanced Safety
• Quick Solution For Real-Time Excel Recording & Reporting
• Field-Ready Instruments With Large Format Display & Ruggedness
• Differential Inputs For All Channels

Typical Applications For Data Logging Equipment:
• Manufacturing Industries (Automotive | Aerospace | Military)
• Research & Development | Quality Control | Inspection | Service & Maintenance
• Medical | Food | Agriculture
• Transportation | Energy | Utility Supliers

Data Platforms

Graphtec GL7000

Key Features
• Analog Low Pass Filter For Noise Cancellation
• Versatile Input Modules For Various Signal Levels
• Standalone System
• Enhanced Memory Capability For Extended Recording
• Compatible With Other Graphtec GL Data Loggers
Software Package Included
• Dual Sampling Capability
• 8 Different Measurement Modules Available
• Connectivity: Ethernet | USB | Wireless LAN Capabilities
• Compatible With Windows | iOS | Android
• Warranty: 3 Years

Data Acquisition Units

Graphtec GL2000

Key Features:
• 7″ Wide TFT Colour LCD Screen
• 4 Channel High Speed Simultaneous Sampling
• Extended Memory Capacity Using SD Cards
• Multifunctional Input With Cat III Measurement Category
• Quick And Easy Set Up Process
• Supports Large Built-In RAM (4MS/CH)
• Built-In 4GB Flash
• Insulated Multifunctional Analog Inpur Port
• Smartphone Remote Access Monitoring Capability
• Connectivity: USB & Wireless LAN Capabilities
• Compatible With Windows | iOS | Android
• Warranty: 3 Years

Graphtec GL980

Key Features:
• 7″ Wide TFT Colour LCD Screen
• Three Types Of Power Source: AC, DC, Battery Pack
• Large Built-In RAM
• Built-In 4GB Flash Memory
• All Channels Isolated
• Ideal For Voltage & Temperature Measurements
• Logic/Pulse Signal Input Port Up To 4 Channels
• Insulated Multi-Function Analog Input Port
• Smartphone Remote Access Monitoring Capability
• Connectivity: USB & Wireless LAN Capabilities
• Compatible With Windows | iOS | Android
• Warranty: 3 Years

Midi Data Loggers

Graphtec GL840

Key Features:
• 7″ Wide TFT Colour LCD Screen
• Three Types Of Power Source: AC, DC, Battery Pack
• Channels: 20 As Standard | Expandable Up To 200
• Expandable Memory With SD Cards
• All Channels Isolated
• Digital Sensor Connection Port
• Logic/Pulse Signal Input Port Up To 4 Channels
• Records Voltage, Temp, Humidity, Pulse & Logic Signals
• Smartphone Remote Access Monitoring Capability
• Connectivity: Ethernet | USB | Wireless LAN Capabilities
• Compatible With Windows | iOS | Android
• Warranty: 3 Years

Graphtec GL240

Key Features:
• 4.3″ Wide TFT Colour LCD Screen
• Three Types Of Power Source: AC, DC, Battery Pack
• Extended Memory Capacity Using SD Cards
• Max Sampling Interval Up To 10ms/1 Channel (100ms For All 10 Channels)
• All Channels Isolated
• Alarm Output Ports (x4)
• Logic/Pulse Signal Input Port Up To 4 Channels
• Records Voltage, Temp, Humidity, Pulse & Logic Signals
• Smartphone Remote Access Monitoring Capability
• Connectivity: USB & Wireless LAN Capabilities
• Compatible With Windows | iOS | Android
• Warranty: 3 Years

Remote Recording Stations

Graphtec GLT400

Key Features:
• Monitorless And Ideal For Use Within Equipment & Control Panels
• Can Be Used In Harsh Temperature Environments
• Channels: 20 Analog As Standard | Expandable Up To 200
• Expandable Memory With SD Cards
• 10ms Sampling Speed
• Records Voltage, Temp, Humidity, Pulse & Logic Signals
• Smartphone Remote Access Monitoring Capability
• Connectivity: Ethernet | USB | Wireless LAN Capabilities
• Compatible With Windows | iOS | Android
• Warranty: 3 Years

Graphtec GL100

Key Features:
• Compact LCD Readout Display
• Compact Handheld Design
• PC & Smartphone Device Software Available
• Industry-Specific Software: Agriculture | Logistics | Power
• Wireless Access For GL100-WL Model
• Self-Triggering Data Acquisition
• Built-In Memory – 4.9MB
• Expandable Memory Via SD Card Port
• Compatible With Windows | iOS | Android
• Warranty: 1 Year

Please Get In Touch If You Require Further Information About Our Instrumentation Products
